Cicada
$12,990.00
CICADA is the first three-wheel LEMS on offer.
CICADA has undergone stringent stability testing while driving, and we can report it is very stable, impossible to tip over.
Worldwide there are more three-wheeled units of this type (including Tuk Tuks) sold than four-wheeled.
CICADA , TGA Registered, with EEC/EC Certification, super price competitive, quality built, (Most) Luxury Enclosed Cabin Mobility Scooter, a LEMS.
CICADA is marketed by Weiyun Motor Co, and is of superior quality and excellent value for money LEMS (Luxury Enclosed Mobility Scooter).
All our LEMS come with “LEMS.COM.AU” Number Plates, WHEELCHAIR and “LUXURY ENCLOSED MOBILITY SCOOTER” signage.
Book in a Trial Today
Description
CICADA, 2024 model, same as the Piccolo 2023 except a three-wheeler mobility scooter with the addition of a foot brake.
CICADA is the cheapest high spec LEMS and most price competitive, quality built, (Most) Luxury Enclosed Cabin Mobility Scooter, a LEMS.
TGA approved, ARTGA registration, with EEC/EC Certification.
CICADA is a great looking LEMS with smooth sleek lines, a high gloss and a luxurious interior, adjustable high quality Leather Captain Seat with three point retractable seat belt, spacious rear seat with lap seat belt, for 2x passengers (you will be required to obtain local road regulators approval) but otherwise great for shopping etc., push button start, remote electric doors and electric windows, sunroof opening window, rear opening window, window wiper with washer, rear view mirrors, reversing camera, and a heater and demister for use on those colder days in winter.
Comfortable in your luxury enclosed mobility scooter, LEMS.
CICADA has three speeds, very sure footed, amazingly wonderful turning circle due to its single front wheel, with absolute control, and very sedate in confined busy footpath situations, thanks to the superb throttle and controller combination.
Features & Equipment
- Two door – keyless entry
- Handle bar steering and controls
- Luxury LCD instrumentation
- Maximum range of up to 80 km *
- Three maximum speeds 8/14/20 kph
- Maintenance Free Deep Cycle Lithium Battery
- Front hydraulic damping strut and rear integral damping suspensions
- Front and rear hydraulic disk brakes
- Handle bar and foot braking
- Parking brake
- 60V brushless DC motor
- Heavy duty controller – soft start, very smooth throttle control
- Weight capacity 200kg
- EEC / EC Certification* Depends on user mass, terrain and battery type and condition, based on 80 kg driver on straight and level smooth hard ground, all things in good condition, and a steady speed.
Equipment
-
- Handle bar steering and controls
- Windscreen wiper with washer
- Remote keyless locking doors
- Electric windows
- LCD electronic instrument dashboard
- Radio, Blue tooth, USB, Auxiliary
- Media display with multi display function control
- Battery capacity gauge
- Speed display and digital
- Odometer / Trip
- Speaker
- Rear vision mirrors
- Rear view camera
- Rear plate light
- Key start / stop
- Heater and demister
- Lights powerful and elegant
- High / low beam head lights
- Indicators
- Three electronic maximum speeds
- Horn
- Large roof window opening
- Rear window opening
- Large wheels with low profile pneumatic tyres for a sure-footed ride
- Hydraulic disk brakes three wheels
- Hand and foot brakes
- Parking brake on rear wheels
- Sliding / tilting luxury leather front Captains seat
- Seatbelt, lap and diagonal
- Large space inside rear for shopping and goods, for passengers (recommend getting local road authority approval)
Other: Comfortable Luxury Captains Safety Seat movable and reclining with lap/shoulder seat belt, Central Handle Bar Steering, Stylish High Definition Liquid Crystal Display, Remote Electric doors, Electric windows, Sun roof opening, Rear opening window, Aluminium rims, Reversing camera, Three-wheel hydraulic suspension, three-wheel disk brakes, effective hand brake.
EEC/CE Certificate covers all vehicle manufacturing requirements, based on European / Australian Standards.
Specifications
Manufacturer: Aera New Energy (Xiamen) Co Ltd
Exporter: Weiyun Motor Co
Importer: Ronica Trade Pty Ltd
Model Number: SQ3
Model: Piccolo
Model Version: Cicada 2024
Certification: EEC / EC
Registration: TGA / ARTGA
Available Colour: Sandy green / White roof
Dimensions: 230 x 100 x 149.5 cm (L x W x H)
Weight (total): 298 kg
Weight without battery: 270 kg
Weight capacity: 200 kg
Maximum speed: 20 kph (3 maximum speeds 8/14/20 kph – Std/Eco/Sport)
Do not exceed 10 kph on paths with pedestrians. Give way to everyone ! Be careful, patient and respectful of others.
Maximum range *: Up to 75 km ( per battery in ideal conditions )
Typical range: 45 km
Heater / demister: Yes
Display: HD LCD Touch Screen easy viewing
Steering: Handle Bar
Braking: Hand and foot, Hydraulic disk all wheels
Parking Brake: Yes
Suspension: Front; telescopic fork Rear; Integral – both hydraulic damping
Tyres: Front 120/70-12, Rear125/65R-12
Pressure: Front: 250kPa, Rear: 250kPa
Rims: Aluminium Alloy
Motor: 60V 1500W brushless DC
Battery: 50 Ah Lithium (80 Ah optional)*
Battery charger: 60V 8A
Controller: Heavy duty soft start
Shipping details (Pallet / Transporter): 360 / 300 kg 226x125x170 cm 4.8 cubic meters
* Varies with user weight, terrain type, driving style, battery charge, battery condition, temperature, and tyre / wheel type and condition. Information taken from manufacturers specifications.
Cicada 2024 is identical to Piccolo 2023 except it is has three wheels and foot brake, the second iteration.
PICCOLO Motor and Battery Description
CICADA, has a 60V 1500W Brushless DC motor.
CICADA has a 50Ah Lithium NiCoMnO2 battery. LiNiCoMnO2 battery is so much better than the Lead Acid Battery, in many ways, including much improved performance and overall driving cost.
In practice depending on driving style, terrain, load, speed, climate, etc, CICADA will take you between 35-40 km distance with the 50Ah battery. You may get more, but remember Lithium batteries have a short end phase in their power supply, so run out quickly.
The CICADA 50Ah Lithium NiCoMnO2 battery has an actual expected 45 km travel distance.
An optional battery, having a capacity of 100 Ah is available giving a total range of about 90 km.
The CICADA NiCoMnO2 battery should be charged when the battery has been discharged to 80% DOD (20% SOC). [DOD is Depth Of Discharge : SOC is State Of Charge] This will be when the battery charge shows about 57V while driving at a steady speed on the flat.
Do not let the battery voltage go below 55V at any time while driving. At 52V, the BMS will switch off to protect the battery.
The CICADA NiCoMnO2 battery life-span is rated at 500 cycles if treated properly.
In summary, with regular heavy use they will do 500 cycles, and last 3-5 years.
Please note, this information is as per this particular type of Lithium battery and is not what you may know or be told about other types of Lithium batteries.
FAQ's
Does a Cicada / Mobility Scooter need to be registered?
In Australia you do not register your Mobility Scooter, except in Queensland, and it is registered for ownership only.
Can I drive my Cicada / Mobility Scooter on the road?
You may drive your Cicada / Mobility Scooter on a public road if for any reason the footpath is not suitable. You must obey all the rules of a pedestrian or cyclist.
You may drive it on any private road, at any time.
What materials is the Cicada made from?
The Cicada panels are made from ABS, an impact-resistance engineering thermoplastic. The windscreen and windows are made from Safety Glass, so they will not shatter into shards that cut you if broken. The frame construction is one piece steel.
How often should I charge my Cicada / Mobility Scooter ?
Charge the battery when no less than 20% charge (SOC). This is after around 35-40 km driving, depending on several driving factors.
When the voltage drops to about 57 volts while driving on the flat, it is time to recharge. When the resting Voltage (when you first turn the key on) drops to 59V it must be charged.
When charged, disconnect the charger and use your Cicada as required.
When in storage, the Lithium battery should be at approximately 62-63 V, half full, or half empty, and make sure the Cicada‘s Power / Overload switch is OFF, so there is no chance of accidentally drawing current from the stored battery. Even better, turn off the battery BMS, switch on battery.
If the battery goes below 49 volts, the BMS (battery management system) will switch off to protect the battery, and the battery will need to be returned to Ronica Trade to try and remedy the situation. There is a 250.00 fee (if successful) to attempt the resurrection, and no guarantees.
So, checking the battery monthly is advised.
What is the average life of a Cicada / Mobility Scooter battery?
The Cicada lithium batteries last around 500 full use cycles (100-20% SOC). To ensure the battery lasts as long as possible, follow the charging instructions as in the previous question.
Why is the Cicada Lithium battery so much better than a Lead-Acid battery?
Firstly, the voltage platform is higher for a Lithium battery, and thus there is more power produced by the motor, and more consistently.
Secondly, the power available (power density) is much greater, making the battery much lighter, and thirdly the power is able to be delivered faster.
Lastly, the ideal temperature for all batteries is 25 C. Temperature limits are, for Lead Acid 0-+35 C, for the Daisy Lithium battery it is -20-+45 C. Temperatures over 35 C damage lead acid batteries.
What is the running cost of a Cicada ?
The electric power cost for the Cicada is approximately 1.3 cents/km.
As in all electric mobility devices, it is the cost of the battery that is the expensive part.
The total running cost of a LEMS is about 13 cent/km plus any servicing.
Can I use other batteries in my Cicada ?
You could use another type of battery in the Cicada, but the type installed from new is by far the best for the job, as explained in the answers above.
We recommend to only install the correct battery available from your dealer or directly from Mobility Scooters for Hire Sale Service.
What is the service schedule for Cicada?
Cicada requires a service every year or 1000km. Change the differential oil with SAE 80-90 gear oil as per the manual. Oil and use 3in1 oil on all joints and moving parts. Wash with running water and a very soft cloth or brush, and wipe as required with a damp soft cloth. Do not use detergents or other cleaners, they are not required. Never wipe in a dry condition, as the dust and sand will scratch surfaces. You may use a UV protectorate or quality polish on the paintwork to protect the sheen from UV damage from the harsh Australian sun.
What is the correct way to connect the power to the charger?
Operation Instructions :
Connect outlet plug of the charger to the Cicada.
Connect the inlet plug of the charger to AC power socket, and when or if connected, turn the power switch on.
When the indicator light is RED it is charging (sometimes this maybe flashing at around one second intervals). When GREEN it is fully charged.
Charging time is proportional to the power required to fully charge the battery, and that is what was used since the last charging.
To disconnect the charger, turn off or remove the charger input plug from the AC power supply.
Remove the charger outlet plug from the Cicada.
Notes :
Do not use outside in the sun, rain or damp
Do not use in dusty conditions
Do not place on inflammable materials
Do not use inside Cicada
Do not drop
Ensure the correct charger is used for correct battery type and capacity.
Some chargers have different colour light sequences, please check and note when first using.
