Specifications
| Item | Specification | Details |
| Performance | Highest Speed | About 25 km/hr | NOTE : read the mph as kph |
| Range * | About 75 km | See note below |
| Safe climbing angle | About 15° | 60 kg riders up to 18° |
| Battery | 12 V, 4 x 18 Ah | |
| Temperature | -10~40° C | Best at 10°~30° C |
| Capacity | 100 kg | |
| Charging | About 6 – 8 hrs | AC 100V-240V,smart charger |
| Motor | 48 V 500 – 800 W | Brushless Motor |
| Controller | 48V Intelligent brushless controller |
| Suspension | Front hydraulic, rear spring and damper |
| Braking | Electronic regenerative electromechanical, plus front and rear hand brakes |
Appearance
Weight | Colour | Silver | |
| Size | 1350*750*1150 mm | |
| Display | LED | |
| Wheel base | 1080 mm | |
| Ground clearance | 125 mm | |
| Rim | Aluminium alloy |
| Tire size | 300-10 |
| Tire pressure | 40 psi ( Do not under or over inflated ! ) |
| Nett weight | 100 kg | |
| Rated load | 100 kg | |
| Safety Measures | Reverse | Slow speed
Continuous Beeping | Emergency Flashers & Rear lights activated |
| Speed limit protection | Two speeds | 0 – 16 km/hr plus variable max speed
0 – 25 km/hr |
| Hand brake | Rear wheel lockable | |
| Low power protection | Turns off when power below 10% | |
| Headlights | Low and high beam | Anti-thieft alarm |
| Indicators | Front and rear | |
| Alert | Power and Error | Power LED indicator | Illuminates when on, flickers when protection activated |
| Battery | Power level indicator | Like fuel gauge |
| Alert sound | Beep | At power on; continual beep reversing |
| Attachments | Standard accessory | Charger | AC 100V-240V,smart charger |
| Other accessories | Rear view mirrors
rear anti tip wheels | Rear closed basket
Glove box compartment lockable
– 2 x cans
Under seat storage lockable |
| |
* Varies with user weight, terrain type, battery charge, battery condition, and tyre condition.
