Specifications
Manufacturer: Ningbo Jiahe Special Vehicle Co
Model: JH01-1A-B
Available Colours: Red / Blue
Length: 121 cm
Width: 69 cm
Height: 130 cm
Weight: 114 kg
Weight Capacity: 150 kg
Turning radius: 120 cm
Maximum speed: 13.5 km / hr
Maximum range *: Up to 40 km ( in ideal conditions )
Maximum slope: 15°
Ground clearance: 14.5 cm
Obstacle Ability: 8 cm
Seating: Capitol high back reclining swivel sliding seat, lift up arm rests
Drive train: Rear 24 V 800 Watt
Braking: Electro-mechanical Regenerative
Wheels: Alloy
Tyres front: 275 mm pneumatic 4.10/3.50-4
Tyres rear: 325 mm pneumatic 4.10/3.50-6
Tyres pressure: 30 – 35 psi
Batteries: 2 x 12 V x 44 Ah
Battery charger: Off board 5 Amp
* Varies with user weight, terrain type, driving style, battery charge, battery condition, temperature, and tyre / wheel type and condition. Information taken from manufacturers specifications.
