Specifications
- Manufacturer: Ningbo Jiahe Special Vehicle Co
- Model: JH07-558A-B
- Available Colours: Blue / Charcoal Grey
- Dimensions: 133 x 69 x 136 cm (L x W x H)
- Weight (total): 115 kg
- Weight capacity: 120 kg
- Turning radius: 120 cm
- Maximum speed: 10 kph
- Maximum range *: Up to 48 km
- Maximum slope *: 15 °
- Ground Clearance: 9.5 cm
- Obstacle Ability: 8 cm
- Seating: Capitol high back reclining swivel sliding seat, lift up arm rests
Weight : 22 kg, size : 61x51x48 cm
- Motor: Rear 24 V 500 Watt
- Control operation: Wigwag paddle
- Braking: Electro-mechanical Regenerative
- Wheels: Alloy
- Tyres rear: 300 mm pneumatic (400-4)
- Tyres front: 300 mm pneumatic (400-4)
- Tyres pressure: 30 – 35 psi
- Batteries: 2 x 12 V x 44 Ahr
- Battery charger: Off board 5 Amp
* Varies with user weight, terrain type, driving style, battery charge, battery condition, temperature, and tyre / wheel type and condition. Information taken from manufacturers specifications.
